Hikvision DS-2DF8436IX-AELW - 4 MP 36× Network IR Speed Dome

Name: Hikvision DS-2DF8436IX-AELW - 4 MP 36× Network IR Speed Dome
Brand: Hikvision
SKU: ZS00000081
Price: 1275.82 GBP

In stock

SKU

ZS00000081

Product Features

1/1.8” HD CMOS sensor
Up to 2560 × 1440 resolution
36x Optical Zoom
Min. Illumination:

Color: 0.002 Lux @(F1.5, AGC ON)
B/W: 0.0002 Lux @(F1.5, AGC ON)
0 Lux with IR

Smart Tracking
Smart Detection
200m IR distance
Optional wiper(-W)
Hi-PoE / 24VAC power supply
Support H.265+/H.265 video compression
Deep-learning-based target classification algorithm for auto-tracking 2.0 and perimeter protection
IP67, IK10

Product Specifications

Downloads

Product Reviews

More Information
Product Code	DS-2DF8436IX-AELW
Manufacturer	Hikvision
Colour	White
Max Resolution	4MP
Video Compression	Main Stream: H.265+/H.265/H.264+/H.264
Min. Illumination	Color: 0.002 Lux @(F1.5, AGC ON)
WDR	120 dB
Lens Size	5.7 mm to 205 mm
FOV	Horizontal field of view: 59.8° to 2.0° (Wide- Tele) Vertical field of view: 33.6° to 1.1° (Wide- Tele) Diagonal field of view: 68.6° to 2.3° (Wide- Tele)
Angle of adjustment	360° endless
Max. IR Range	Up to 200 m
VCA	Intrusion, Line Crossing, Region Entrance, Region Exiting Support alarm triggering by specified target types (human and vehicle) Filtering out mistaken alarm caused by target types such as leaf, light, animal, and flag, etc. Face Detection, Audio Exception Detection Manual Tracking, Auto Tracking (support tracking specified target types such as human and vehicle), Event Tracking ANR (Automatic Network Replenishment), Dual-VCA
Frame Rate	50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
Streams	3
Protection Level, Ingress Protection	IP67 Standard, IK10 (only supported bycamera without wiper), TVS 6,000V LightningProtection, Surge Protection and VoltageTransient Protection
Operating Temperature	Outdoor: -40°C to 70°C (-40°F to 158°F)
Humidity	0.9
Audio I/O	1-ch audio input (applicable microphone,plug-in power type), 2 to 2.4 V[p-p], 1 KO ±10%
Alarm I/O	7-ch alarm input/2-ch alarm output
Local Storage	Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/CIPS), ANR
Power	24 VAC (Max. 60 W)
Optical Zoom	36× Optical zoom
Tilt Range	From -20° to 90°
Tilt Speed	Configurable, from 0.1°/s to 150°/s, PresetSpeed: 250°/s
Pan Speed	Configurable, from 0.1°/s to 210°/s, PresetSpeed: 280°/s
